Orange Multimode OM3 SC PC 50/125nm Fiber Optic Pigtail

Brand Name : Geehe (OEM&ODM)

Model Number : GH-FP-Pigtail-0018

Certification : ISO9001:2015,ISO:14001:2015,UL

Place of Origin : Wuhan,China

MOQ : 10,000pcs

Price : Negotiation

Payment Terms : T/T, D/A, Western Union, MoneyGram,Cash

Supply Ability : 10,000 pcs per day

Delivery Time : Within 5-7 working days to delivery

Packaging Details : PE bags per piece with thick outer cartons,OEM details

Model Name : Multimode Fiber Optic Pigtail

Fiber Type : Single Mode

Connector A : SC connector

Cable Jacket : PVC/LSZH/OFNP

Wavelength : 1310 nm/1550 nm

Cable Length : 1M, 2M, 3M,20M,100MOr Customized

Cable Color : Yellow, Aqua, Purple, Violet Or Customized

Cable Diameter : 0.9mm, 1.8mm,2.0mm, 3.0mm

Minimum Bend Radius : 30 mm/10 mm

Durability : ＞1000 times

Contact Now

SC/PC Multimode Fiber Optic Pigtail OM3 Orange Jacket 50/125nm simplex

Basic Information:

Our Pigtail fiber optics are an excellent option to use as a termination of the cables you are installing, where you will get an unmatched quality in the termination of the link and save time in the organization of the fibers within an optical distributor.

The quality of our Pigtail fiber optics is guaranteed since all are verified by measurement tests in order to ensure compliance with the established measurement parameters.

We also offer 6 and 12 piece kits that come configured according to the color code TIA-598-A:


1-6: Blue, Orange, Green, Brown, Grey, White

7-12: Red, Black, Yellow, Purple, Pink, Aqua high

Orange Multimode OM3 SC PC 50/125nm Fiber Optic Pigtail

Features And Benefits of SC Pigtails

  • Quality according to IEC 61755-1 class C2
  • 0.9 mm cable for splicing ODF
  • Tight secondary coating (100 mm strip length)
  • 4, 6, 8, 12, 24, 48 fibers optional
  • With heat shrinkable tube
  • Cable material: PVC, OM1, OM2, or OM3 optional
  • Single-mode or multi-mode

Applications of SC/APC Single Mode Pigtails:

  • Active Device Termination
  • Premise Installations
  • Telecommunication and Data processing Networks
  • Industrial, medical & military
  • Systems Integration for Long Haul, Metro, and Access Network

Orange Multimode OM3 SC PC 50/125nm Fiber Optic Pigtail

Specification &Technology Parameters:

Item SM (Single-Mode) MM (Multimode)
Fiber Cable Type G625D/G655/G6571A/G657A2 OM1 OM2/OM3/OM4
Fiber Diameter (um) 9/125 62.5/125 50/125
IL(dB) ≤0.3 ≤0.1
Cable Type Simplex, Duplex, Fan-Out
Connector Type LC, SC, FC, ST, MU, MPO, MTRJ, D4, DIN, SMA, FDDI,
ESCON etc.
Cable OD (um) 0.9/1.6/1.8/2.0/2.4/2.8/3.0
End-face Type PC UPC APC UPC UPC
Retun Loss(dB) >45 >50 >60 /
Insert-pull Test (dB) <0.2 <0.3 <0.15
Interchangeability (dB) <0.1 <0.15 <0.1
Mating Times >1000
Anti-tensile Force (N) >70
Temperature Range (℃) -40~+80

SC /PC Single Pigtails Specification:

Parameter Unit Index
End-Face Type PC UPC APC
IL dB SM: ≤0.3; MM ≤0.1
Repeatability dB ≤0.1
Interchangeability dB ≤0.2
RL SM dB ≥45 ≥55 ≥60
MM dB ≥36(Exclusive APC Connector )
Mating Times ＞1000
Operating Temperature ℃ -40~ +80

SC Ordering Information:

OFC -X -XX -XX -XX -XX -XX
S: Simplex D: Duplex SA:SC/APC SC:SC/UPC SP:SC/PC SA:SC/APC SC:SC/UPC SP:SC/PC 09:0.9mm 20:2.0mm 30:3.0mm 0:G652D 1:G657A 2:50/125 3:62.5/125 4:others 0.5:0.5m
1.0:1.5m
10:10.0m
Fiber Mode Connector Type Connector Type Cable Diameter Fiber Type Fiber Length

More SC Connector Options:

Orange Multimode OM3 SC PC 50/125nm Fiber Optic Pigtail
